Butter Foil Packaging Machine

DESCRIPTION OF THE MACHINE  - general data

²  Main dimensions: lenght x width x height

2,3 m     2,8 m    1,55 m

²  Weight:           1450 kg

²  Feeding of packing：adjustable by transport rollers

²  Packing material: aluminium foil, greaseproof paper or other suitable materials

²  Packing format:    lenght x width x height

min 70 x 50 x 31 mm,

max 100 x 75 x 43

²  Dosing range:       50 g – 300 g

²  Folding: adjustable, setting up the folding depending on used packing material

²  Discharge: via conveyor belt, height above the floor 840 +/- 20 mm, adjustable, horizontal, continuous

²  Centering device

(optional):       adjustable, photocell - (optional)

²  Coding device: thermoprint by thermo-pressing-ribbon (various colours) - (optional),  or any kind of Ink-jet (depending on customer choice) or just a signal to customer´s   existing dating device

²  Output:adjustable in range from 60 up to 110 cycles/min, depending on the quality of the packing material and product consisency

²  Engine: 3 phase engine (2.2kW; 1.500 rpm) with brake frequency changer with regulator, voltage system 220V / 60 Hz

FUNCTION PRINCIPLE – general data

The wrapping material is fed from the reel, cut laterally and placed into a cell in the turn table, where it forms an open wrapper bag. The pasty product, fo pumpable consistency, is volumetrically dosed and filled into the wrapper bag. Finally, the packet is closed and calibrated, thus ensuring sharp edges.

STANDARD OUTFIT – adapted for this concrete demand

²   Basic packaging format 100x75mm with variable height 29-36mm for dosing range 200-250g

²   filling head designed for direct input of the product including compensator safety features including safety sensors

²   Safety guarding and stainless steel covering of the machine – high version (acrylic glass as shown on the picture above)

²   frequency changer with regulator

²   control case: el. switch board on the machine

²   computer control: PLC SIEMENS – touch screen with visualition

²   stainless steel trough with augers and cover

²   centering device with photocell

²   central system of lubrication

²   no dating device in basic outfit, just signal to customer´s  existing dating device if any
